0558842084Highlights
1. Function overview :
➢ This series has a cabinet-like appearance and is coated with cold-rolled steel plates. It can be widely used in building lobbies, hospitals, stations, hotels, subways, shopping malls, government buildings and other places. It is mainly used for multimedia information disclosure, POP slideshow picture advertisements, text, audio Video media playback is a high-end digital signage commercial display product.
| Panel size (Panel) | 36.2 inches |
| Display area size (Active area) | 885 (width)× 249 height)mm |
| LCD screen brand (Panel brand) | LED, brand: |
| Display mode (Aspect ratio) | 32:9 |
| Resolution (Max resolution) | 1920*540 |
| Display colors ( Support Colors ) | 16.7M |
| Pixel pitch _ _ _ | 0. 46 * 0. 46 mm |
| Brightness nits | 35 0 cd/㎡highlight |
| Contrast ratio | 1000:1 |
| Viewing angle | R/L/U/D 89/89/89/89 |
| Response time | < 8ms |
| Field rate | 60HZ |
| Theory lifetime | 50000H |
| Power consumption (kw/h) | < 30W _ |
| Basic parameters of appearance | |
| Body color | |
| Appearance size (Body size) | |
| Black border size | |
| Product Weight | |
- Functional specifications:
| Hardware parameters | ||
| CPU | Allwinner A 40i Cortex-A7 quad- core CPU, equipped with Android 7.1 system , with a main frequency of up to 1.2 GHz. | |
| running memory | 1G DDR3 | |
| memory | eMMC 8 GB (expandable) | |
| Decoding resolution | Supports up to 1080P HD video | |
| interface | Expansion SD card slot*1
RJ45 interface*1 HDMI high-definition output*1 USB interface*2 |
|
| Menu language (Osd language) | Support Chinese and English | |
| file format
(FILE FORMAT) |
Video | RMVB, FLV, MPEG1/2/4, AVI, DIVX, XDIV, WMV9, H.264, VC-1, MOV, MKV, MP4, TS, M2T, VOB |
| Picture _ _ | BMP/PNG/GIF/JPEG | |
| Music | MP3, WMA, WAV, EAAC+, MP2 dec, Vorbis(Ogg), AC3, FLAC (lossless audio), APE (lossless audio), BSAC; | |
| Speaker | 2* 5W (8Ω) | |
| Hardware features (Play mode) | 1. It uses Allwinner A 40i Cortex-A7 quad- core CPU, equipped with Android 7.1 system , with a main frequency of up to 1.2 GHz . It can replace the entertainment functions of desktop PCs, and the platform has the advantages of standardization and openness;
2. Supports free switching of HDMI/VGA boot output; 3. Input function: supports resistance, capacitance, infrared, sound wave, nanometer and other touch screen input; supports remote control Control input, supports USB mouse/keyboard input; 4. Supports horizontal and vertical screens at startup, and 360-degree display mode; 5. Multiple storage media support function: can support SD card, USB disk, SATA hard disk peripheral storage; 6. Clock display: built-in clock IC, can automatically update time information online and automatically correct system time; 7. Timing on and off: It is beneficial to save energy and extend its service life; after setting the on and off time, the entire system will automatically start during the boot time period; 8. Powerful network support: supports wired/Wifi/3G (optional) access; 9. Multi-language: supports Chinese, English and other most national languages, TTF vector font support, display No distortion; 11. Supports a variety of B/S architecture advertising publishing software. Based on the powerful back-end server management software support, it can Set advertising machine parameters online, create and distribute playlists online, download server advertising film sources in real time/scheduled time, and automatically play after downloading; |
|
| Control background software | have | |
| Other functional parameters | |
| touch | none |
| WIFI | 802.11B/G/N |
| 3G | none |
- Usage environment:
| Usage environment | |
| Operating temperature: | 0℃～40℃ |
| Storage temperature: | -20℃～60℃ |
| Air humidity: | <85% |
| Operating Voltage: | ~100V-260Vac 50Hz/60Hz |
